YHMM300B Precision Vertical Double Side Grinder
Category: Product Center
Keywords: Yuhuan
Processing Methods
Suitable for high-efficiency, multi-specification and variety processing
Suitable for thick workpieces, workpieces with verticality requirements, large removal amount
Equipment Highlights
● The precise and stable grinding angle adjustment technology of the upper grinding head.
● High rigidity and high precision spindle support structure and double nut sliding sleeve technology.
● High-precision feed system design.
● High precision and smooth grinding wheel dressing technology.
● High rigidity feeding mechanism design.
Technical Parameter
|
Item/Product Model |
Unit |
YHMM300B |
|
Workpiece diameter |
mm |
Φ10-Φ80 |
|
Workpiece thickness |
mm |
8-40 |
|
Wheel size |
mm |
Φ305 |
|
Grinding head motor |
kw |
7.5 x 2 |
|
Grinding head speed |
rmp |
50-1000 |
|
Feeding tray motor power |
kw |
1.5 x 3 |
|
Machine quality |
kg |
5000 |
|
Machine tool dimensions (length x width x height (LxWxH) |
mm |
1900x1920x2240 |
